The CFM56-7B Jet Engine is a high-bypass turbofan produced by CFM International, a joint venture between GE Aviation (USA) and Safran Aircraft Engines (France). Designed primarily for Boeing 737 Next Generation aircraft, it is renowned for its fuel efficiency, reliability, and low emissions. Key features include advanced materials, FADEC-controlled operation, and modular construction for ease of maintenance. The CFM56-7B’s widespread use and strong operational record make it one of the most successful jet engines in commercial aviation history. This diagram highlights its major components, airflow pathways, and core systems.
